Quick exhaust valve 1/8 NPT, exhaust 1000 l/min SEU-1/8-NPT - Festo 9798
The SEU-1/8-NPT quick exhaust valve vents a cylinder directly at the port instead of through the line to the directional valve. Main values: port 1/8 NPT, exhaust flow 1000 l/min, operating pressure 0.5 to 10 bar. This increases the piston speed. Ambient temperature -20 to 75 °C. Weight 65 g.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
1000 l/min standard flow rate, exhaust (6 to 0 bar): the SEU-1/8-NPT quick exhaust valve vents a cylinder directly at the port instead of through the line to the directional valve. This increases the piston speed.
Benefits
- Flow rate: standard flow rate, exhaust (6 to 0 bar) 1000 l/min
- Pressure range: 0.5 to 10 bar operating pressure
- Connections: 1/8 NPT
- Paint compatibility: LABS conformity VDMA24364-B1/B2-L
- Temperature: -20 to 75 °C ambient temperature
- Nominal size: 5 mm
Applications
Mounted directly at the cylinder port when large cylinders or long tubing lines must be exhausted quickly. Operating medium: compressed air to ISO 8573-1:2010 [7:-:-]. Mounting: screw-in. Lubricated operation possible, then required.
Technical data
| Type | SEU-1/8-NPT |
|---|---|
| Festo part number | 9798 |
| Valve function | Quick exhaust |
| Additional function | With silencer |
| Pneumatic connection, port 1 | 1/8 NPT |
| Pneumatic connection, port 2 | 1/8 NPT |
| Type of mounting | Screw-in |
| Standard nominal flow rate, exhaust (6 to 5 bar) | 390 l/min |
| Standard flow rate, exhaust (6 to 0 bar) | 1000 l/min |
| Standard nominal flow rate, supply (6 to 5 bar) | 300 l/min |
| Operating pressure | 0.5 to 10 bar |
| Ambient temperature | -20 to 75 °C |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Nominal size | 5 mm |
| Note on operating and pilot medium | Lubricated operation possible (then required for further operation) |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Medium temperature | -20 to 75 °C |
| Sound pressure level | 86 dB(A) |
| Weight (shipping) | 65 g |
| Weight | 0.065 kg |
| Manufacturer | Festo |
| Hersteller-Nr | SEU-1/8-NPT |
| EAN | 4052568303488 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | NPT 1/8 |
| Nominal size DN [mm] | 5 |
| Medium | Compressed air |
| Function | Quick exhaust |
| Flow rate [l/min] | 1000 |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | NPT 1/8 |
| Temperaturbereich | -20-75 °C |
| Temperature (max.) | 75 |
