Pressure sensor 0 to 2 bar, PNP, push-in connector QS-6 SDE5-D2-FP-Q6-P-K - Festo 557322
The pressure sensor SDE5-D2-FP-Q6-P-K monitors relative pressure in the range 0 to 2 bar and switches via a PNP switching output. Push-in connector QS-6 and 2.5 m cable (3-wire). Festo part number 557322, type SDE5-D2-FP-Q6-P-K.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Measuring range 0 to 2 bar: the Festo pressure sensor SDE5-D2-FP-Q6-P-K monitors relative pressure and switches via a PNP switching output.
Benefits
- Measuring range 0 to 2 bar
- PNP switching output, switchable switching element
- Push-in connector QS-6, electrical: 2.5 m cable (3-wire)
Application
This allows supply pressure, test pressure and pressure drop on machines to be monitored directly.
Technical data
| Type | SDE5-D2-FP-Q6-P-K |
|---|---|
| Pressure measuring range initial value | 0 bar |
| Pressure measuring range full scale value | 2 bar |
| Measured variable | Relative pressure |
| Switching function | Freely programmable |
| Switching element function | Switchable |
| Pneumatic connection | QS-6 |
| Switching output | PNP |
| Electrical connection | 3-wire, cable |
| Cable length | 2.5 m |
| Manufacturer | Festo |
| Hersteller-Nr | SDE5-D2-FP-Q6-P-K |
| Zolltarifnummer | 90262020 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
