Pressure sensor 0 to 10 bar, PNP, push-in connector QS-4 SDE5-D10-O2-Q4E-P-M8-0.5X-1.2Y - Festo 609796
Designed for pressures of 0 to 10 bar, the pressure sensor SDE5-D10-O2-Q4E-P-M8-0.5X-1.2Y measures relative pressure and switches via a PNP switching output. It connects pneumatically via push-in connector QS-4 and electrically via M8x1 plug (3-pin).
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo pressure sensor SDE5-D10-O2-Q4E-P-M8-0.5X-1.2Y measures relative pressure in the range 0 to 10 bar and switches via a PNP switching output.
Benefits
- Measuring range 0 to 10 bar
- Push-in connector QS-4, electrical: M8x1 plug (3-pin)
- PNP switching output, N/O contact
Application
This allows supply pressure, test pressure and pressure drop on machines to be monitored directly.
Technical data
| Type | SDE5-D10-O2-Q4E-P-M8-0.5X-1.2Y |
|---|---|
| Pressure measuring range initial value | 0 bar |
| Pressure measuring range full scale value | 10 bar |
| Measured variable | Relative pressure |
| Switching function | Threshold value with variable hysteresis |
| Switching element function | N/O contact |
| Pneumatic connection | QS-4 |
| Switching output | PNP |
| Electrical connection | M8x1, 3-pin |
| Weight (price list) | 55 g |
| Weight | 0.055 kg |
| Manufacturer | Festo |
| Hersteller-Nr | SDE5-D10-O2-Q4E-P-M8-0.5X-1.2Y |
| Zolltarifnummer | 90330090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Measuring range max. [bar] | 10 |
| Function | NO contact |
