Angle seat valve, pneumatic, G 1", 1.4408, normally open, standard

The angle seat valve shuts off liquids, steam and gases in an inclined seat with a low pressure drop. The article is made of stainless steel 1.4408. The data give connection G 1" and installation length 90 mm. The version is listed with the normal position open and the version standard.

Benefits

• Working pressure range 0 - 16 bar at connection G 1".
• Medium temperature -40 to +200 °C at an ambient temperature of -10 to +60 °C.
• Installation length 90 mm, valve body in stainless steel 1.4408.
• Control pressure 4 to 10 bar, 6 bar as the optimum, control port G 1/8 inch.
• Normal position open in the standard version.

Applications

In steam and hot water lines the valve switches at connection G 1" up to -40 to +200 °C.

Standards and conformity

The data give a control pressure of 4 to 10 bar and a control port G 1/8 inch. The standard version sets the direction of flow.
