This bulkhead tube fitting joins the bulkhead thread M 14x1.5 and a tube of 8x6 mm without a further adaptor. Tube 8x6 mm, bulkhead design, material PFA.
Bulkhead tube fitting, bulkhead design, bulkhead thread M 14x1.5, tube 8x6 mm, PFA, -40 bis +180 °C
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€89.38
Item
FL-013152
Manufacturer no.
SCK 6 PFA
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.SCK 6 PFA
EAN4050571615956
Customs tariff number39174000
ConditionNew
Artikel
FL-013152
Frequently Bought Together
-
This Item:
€89.38
-
Push-in fitting, elbow design, male thread G 3/8", tube 10 mm, PVDF, seal FKM
€45.52
-
Push-in fitting, thread R 1/8", tube 8 mm, polypropylene, FDA compliant, stainless steel thread
€18.27
Total price
The bulkhead tube fitting brings the bulkhead thread M 14x1.5 and a tube of 8x6 mm together. The temperature range reaches from -40 °C to +180 °C. The bulkhead design leads the line tightly through a panel or wall.
Benefits
- The temperature range from -40 °C to +180 °C covers cold installation and warm machine surroundings
- PFA keeps the part light and works in the range from -40 °C to +180 °C
- The bulkhead panel may be up to 8 mm thick
- The design follows connection principle 2 of the range
- Approvals to FDA are documented for the materials
- Union nut and clamping ring allow the joint to be released repeatedly
Technical data
| Material | PFA |
|---|---|
| Tube diameter (outside x inside) | 8x6 mm |
| Maximum bulkhead panel thickness | 8 mm |
| Bulkhead thread | M 14x1.5 |
| Connection principle | connection principle 2 |
| Temperature range | -40 to +180 °C |
| Material approvals | FDA |
Applications
Water lines on machines, laboratory equipment and dosing technology, plant construction with frequent modification, tube lines in pneumatics.
Standards and conformity
The following approvals are documented for the materials used: FDA.
| Weight | 0.023000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | SCK 6 PFA |
| EAN | 4050571615956 |
| Zolltarifnummer | 39174000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | PFA |
| Schlauchdurchmesser (außen x innen) [mm] | 8x6 |
| Temperaturbereich | -40-180 °C |
