Bulkhead tube fitting, bulkhead design, bulkhead thread M 18x1.5, tube 12x9 mm, PVDF

The temperature range reaches from -20 °C to +120 °C. The bulkhead tube fitting connects the bulkhead thread M 18x1.5 and a tube of 12x9 mm in doing so. The bulkhead design leads the line tightly through a panel or wall.

Benefits

• The bulkhead panel may be up to 8 mm thick
• Approvals to FDA are documented for the materials
• The seal in FKM is matched to the range from -20 °C to +120 °C
• Union nut and clamping ring allow the joint to be released repeatedly
• The connection over bulkhead thread M 18x1.5 is fixed in size and needs no adaptor

Technical data

Applications

Plant construction with frequent modification, tube lines in pneumatics, laboratory and chemical plants, water lines on machines.

Standards and conformity

The following approvals are documented for the materials used: FDA.
