Bulkhead tube fitting, bulkhead design, thread M 16x1.5, tube 10x8 mm, PVDF, -40 bis +140 °C

This bulkhead tube fitting joins the bulkhead thread M 16x1.5 and a tube of 10x8 mm in one part. The temperature range reaches from -40 °C to +140 °C. The bulkhead design leads the line tightly through a panel or wall.

Benefits

• The design follows connection principle 1 of the range
• Approvals to FDA are documented for the materials
• Union nut and clamping ring allow the joint to be released repeatedly
• The connection over bulkhead thread M 16x1.5 is fixed in size and needs no adaptor
• With tube 10x8 mm the size is fixed, so no reworking of the line is required
• The temperature range from -40 °C to +140 °C covers cold installation and warm machine surroundings

Technical data

Applications

Tube lines in pneumatics, water lines on machines, laboratory equipment and dosing technology, plant construction with frequent modification.

Standards and conformity

The following approvals are documented for the materials used: FDA.
