The push-in fitting saves an intermediate construction because the bulkhead thread G 3/8" and a tube of 6 mm outside diameter meet directly. FDA compliant version, bulkhead design, tube diameter 6 mm.
Push-in fitting, bulkhead design, thread G 3/8", tube 6 mm, POM, FDA compliant
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€4.03
Item
FL-319648
Manufacturer no.
IQSS 60 FDA
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.IQSS 60 FDA
EAN4050571384906
Customs tariff number39174000
ConditionNew
Artikel
FL-319648
Frequently Bought Together
-
This Item:
€4.03
-
Hose stud, BRK vehicle line system, thread M16x1,5, hose 13 mm
€3.02
-
Polyamide tube PA, diameter 12 x 9 mm, red, roll of 25 m, working pressure 19 bar
€99.13
Total price
The push-in fitting accepts the bulkhead thread G 3/8" and a tube of 6 mm outside diameter. The part accepts the tube without tools and holds it by the gripping claws. The operating pressure reaches from -0.95 bar to 16 bar. The bulkhead design leads the line tightly through a panel or wall.
Benefits
- POM, FDA compliant keeps the parts light and dimensionally stable in the range from -0.95 bar to 16 bar
- The bulkhead panel may be up to 13.5 mm thick
- Approvals to NSF and ANSI 51 as well as 61, KTW, WRC, ACS are documented for the materials
- The seal in NBR is matched to the range from -0.95 bar to 16 bar
Technical data
| Material | POM, FDA compliant |
|---|---|
| Tube outside diameter | 6 mm |
| Bulkhead thread | G 3/8" |
| Maximum bulkhead panel thickness | 13.5 mm |
| Operating pressure | -0.95 to 16 bar |
| Design version | FDA compliant version |
| Seal material | NBR |
| Media | lubricated and unlubricated compressed air, non hazardous gases and liquids, water, liquid foodstuffs, mild chemicals |
| Material approvals | NSF and ANSI 51 as well as 61, KTW, WRC, ACS |
Applications
Control air lines inside the control cabinet, workshop distribution and service units, compressed air installation on machines and plants, water and cooling circuits.
Standards and conformity
The following approvals are documented for the materials used: NSF and ANSI 51 as well as 61, KTW, WRC, ACS.
| Weight | 0.008300 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | IQSS 60 FDA |
| EAN | 4050571384906 |
| Zolltarifnummer | 39174000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
