Push-in fitting, bulkhead design, thread G 3/8", tube 4 mm, POM, FDA compliant

The push-in fitting accepts the bulkhead thread G 3/8" and a tube of 4 mm outside diameter. The part accepts the tube without tools and holds it by the gripping claws. The operating pressure reaches from -0.95 bar to 16 bar. The bulkhead design leads the line tightly through a panel or wall.

Benefits

• POM, FDA compliant keeps the parts light and dimensionally stable in the range from -0.95 bar to 16 bar
• The bulkhead panel may be up to 13.5 mm thick
• Approvals to NSF and ANSI 51 as well as 61, KTW, WRC, ACS are documented for the materials
• The seal in NBR is matched to the range from -0.95 bar to 16 bar

Applications

Control air lines inside the control cabinet, workshop distribution and service units, compressed air installation on machines and plants, water and cooling circuits.

Standards and conformity

The following approvals are documented for the materials used: NSF and ANSI 51 as well as 61, KTW, WRC, ACS.
