The push-in fitting saves an intermediate construction because the bulkhead thread M 28x1.5 and a tube of 16 mm outside diameter meet directly. High temperature version, bulkhead design, tube diameter 16 mm.
Push-in fitting, bulkhead design, thread M 28x1.5, tube 16 mm, nickel plated brass
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€37.69
Item
FL-437489
Manufacturer no.
IQSS 160 MSV-V
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.IQSS 160 MSV-V
EAN4050571862589
Customs tariff number74122000
ConditionNew
Artikel
FL-437489
Frequently Bought Together
The push-in fitting accepts the bulkhead thread M 28x1.5 and a tube of 16 mm outside diameter. The part accepts the tube without tools and holds it by the gripping claws. The temperature range reaches from -20 °C to +150 °C. The bulkhead design leads the line tightly through a panel or wall.
Benefits
- Nickel plated brass as material covers the released range from -20 °C to +150 °C
- The bulkhead panel may be up to 22 mm thick
- The design high temperature is clearly designated in the data sheet
- The seal in NBR is matched to the range from -20 °C to +150 °C
Technical data
| Material | nickel plated brass |
|---|---|
| Design | high temperature |
| Tube outside diameter | 16 mm |
| Bulkhead thread | M 28x1.5 |
| Maximum bulkhead panel thickness | 22 mm |
| Temperature range | -20 to +150 °C |
| Design version | high temperature version |
| Seal material | NBR |
| Media | lubricated and unlubricated compressed air, neutral and non hazardous gases |
Applications
Workshop distribution and service units, compressed air installation on machines and plants, pneumatic cylinders and valve terminals, control air lines inside the control cabinet.
Standards and conformity
Only silicone free seals and lubricants are used during assembly.
| Weight | 0.175000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | IQSS 160 MSV-V |
| EAN | 4050571862589 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Hochtemperatur |
| Temperaturbereich | -20-150 °C |
