Push-in fitting, bulkhead design, thread M 17x1, tube 10 mm, nickel plated brass, -20 bis +80 °C

This push-in fitting is designed for the bulkhead thread M 17x1 and a tube of 10 mm outside diameter. The part accepts the tube without tools and holds it by the gripping claws. The temperature range reaches from -20 °C to +80 °C. The bulkhead design leads the line tightly through a panel or wall.

Benefits

• With tube diameter 10 mm the size is fixed, so no reworking of the line is required
• The temperature range from -20 °C to +80 °C covers cold installation and warm machine surroundings
• Nickel plated brass as material covers the released range from -20 °C to +80 °C
• The bulkhead panel may be up to 19 mm thick
• The design standard is clearly designated in the data sheet

Technical data

Applications

Compressed air installation on machines and plants, pneumatic cylinders and valve terminals, control air lines inside the control cabinet, workshop distribution and service units.

Standards and conformity

Only silicone free seals and lubricants are used during assembly.
