This straight bulkhead coupling takes a pipe run through a wall or bulkhead and holds it there with a lock nut. A key figure is a working pressure of 315 bar. Size tube 8 L (M14x1.5), bulkhead M 14x1.5, material stainless steel 1.4571.
Straight bulkhead coupling, tube 8 L, stainless steel 1.4571
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€55.69
Item
FL-014245
Manufacturer no.
SV 8 L ES
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.SV 8 L ES
EAN4050571674632
Customs tariff number73071990
ConditionNew
Artikel
FL-014245
Frequently Bought Together
-
This Item:
€55.69
-
Straight bulkhead coupling, tube 8 L, zinc-plated steel, bulkhead thread M 14x1.5
€5.20
-
Straight bulkhead coupling, tube 6 S, stainless steel 1.4571, NC clamping ring
€51.44
Total price
As a straight bulkhead coupling the article takes a pipe run through a wall or bulkhead and holds it there with a lock nut. Material stainless steel 1.4571 is listed for this version. The data sheet gives a working pressure of 315 bar.
Benefits
- The bulkhead thread M 14x1.5 takes the wall feed-through and is secured with a lock nut.
- Working pressure up to 315 bar for tube 8 L (M14x1.5).
- Temperature range -60 to +400 °C for the body made of stainless steel 1.4571.
- Built as a cutting ring coupling, light series, and removable again.
- Any elastomer seal fitted is made of FKM.
Technical data
| Design | bulkhead coupling |
|---|---|
| Material and scope of supply | stainless steel 1.4571 |
| Series | light series |
| Tube outside diameter | 8 L (M14x1.5) |
| Bulkhead thread | M 14x1.5 |
| Working pressure [bar] | 315 |
| Temperature range [°C] | -60 to +400 |
| Elastomer seal, if fitted | FKM |
| Coupling system | cutting ring coupling |
Applications
On cabinets and tank walls the coupling takes a 8 L (M14x1.5) tube through the wall and holds it over the M 14x1.5 bulkhead thread.
| Weight | 0.085000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | SV 8 L ES |
| EAN | 4050571674632 |
| Zolltarifnummer | 73071990 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Schottverschraubung |
| Material | 1.4571 |
| Rohrdurchmesser (außen) | 8 L (M14x1,5) |
| Series | leichte Baureihe |
| Temperaturbereich | -60-400 °C |
