The die version produces a bore, countersink or thread to a defined size. The data sheet states outside diameter 38 mm as well as thread M 12.
Die DIN EN 22568, coarse thread M 12, outside diameter 38 mm, pitch 1.75 mm
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€13.72
Item
FL-258975
Manufacturer no.
GEW SE M12
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.GEW SE M12
EAN4050571164089
Customs tariff number82074030
ConditionNew
Artikel
FL-258975
Frequently Bought Together
-
This Item:
€13.72
-
Cartridge gun (Loctite), for 310 ml cartridges and 250 ml Tuben (Loctite)
€305.46
-
PVC fabric hose 6 (1/4")x12mm, 10 m with coupling and plug, silicone-free production, 27
€27.83
Total price
When used as a die, the article produces a bore, countersink or thread to a defined size. The article is listed with outside diameter 38 mm and thread M 12.
Benefits
- version coarse thread
- cutting material matched to the workpiece material, verified by outside diameter 38 mm
- made to DIN EN 22568
- thread M 12
- pitch 1.75 mm
- thickness 14 mm
Technical data
| version | coarse thread |
|---|---|
| thread | M 12 |
| pitch [mm] | 1.75 |
| outside diameter [mm] | 38 |
| thickness [mm] | 14 |
Applications
Its place is in metalworking, tool making and assembly. Further stated points are die and form B.
Standards and conformity
The stated standard is DIN EN 22568 and ISO 13.
| Weight | 0.080000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | GEW SE M12 |
| EAN | 4050571164089 |
| Zolltarifnummer | 82074030 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Normalgewinde |
| Thread | M 12 |
| Norm | DIN EN 22568 |
