Hose tail with union nut, thread G 1/4", hose 6 mm (1/4"), PN 16 bar, nickel-plated brass - Fluidics equipment

The hose tail with union nut connects a hose detachably to a threaded port: the tail takes the hose, the nut is screwed onto the counterpart. The union nut has the thread G 1/4", the tail suits hoses with 6 mm (1/4") inside diameter, and the nominal pressure is PN 16 bar.

Benefits

• Tail for hoses with 6 mm (1/4") inside diameter
• Union nut: the hose can be released without turning the line
• Parallel pipe thread G 1/4", sealed with a bonded seal or flat gasket
• Rated for PN 16 bar
• Width across flats 17 mm for fitting with an open-end spanner
• Nickel-plated brass: the nickel layer protects the surface against tarnishing

Applications

Hose connections 6 mm (1/4") on machines, pumps and vessels with G 1/4" thread, for water, compressed air and process media.
