Position indicator aluminium, reinforced PA ATEX SAMH-F12-MK-A2 - Festo 8101084
Makes the actuator position visible on site from the outside. Festo position indicator SAMH-F12-MK-A2 comes with explosion protection Zone 2 (ATEX), Zone 22 (ATEX) and housing made of aluminium, reinforced PA.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Festo position indicator SAMH-F12-MK-A2: explosion protection Zone 2 (ATEX), Zone 22 (ATEX), plus housing made of aluminium, reinforced PA. Makes the actuator position visible on site from the outside.
Benefits
- Explosion protection Zone 2 (ATEX), Zone 22 (ATEX)
- Housing made of aluminium, reinforced PA
- Ambient temperature -20 to 60 °C
- Degree of protection IP65, IP67, dust-tight and protected against water jets
- Corrosion resistance class CRC 2 - moderate corrosion stress
- LABS (PWIS) conformity VDMA24364 zone III
Applications
For limit switch boxes and quarter-turn actuators where the position must be readable on site. For replacements, compare the order code SAMH-F12-MK-A2 with the installed part.
Technical data
| Feature | Value |
|---|---|
| Type | SAMH-F12-MK-A2 |
| Festo part number | 8101084 |
| Mounting position | any |
| Design structure | 2 proximity switches with explosion protection and high IP protection |
| Explosion protection | Zone 2 (ATEX), Zone 22 (ATEX) |
| Application note | When used with angle seat valve VZXA, the SIL approval of the complete product becomes void |
| Note on materials | RoHS compliant |
| Ambient temperature | -20 to 60 °C |
| Storage temperature | -10 to 60 °C |
| Product weight | 151 g |
| Material seals | EPDM |
| Material housing | aluminium, reinforced PA |
| Degree of protection | IP65, IP67 |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Weight | 0.23 kg |
| Manufacturer | Festo |
| Hersteller-Nr | SAMH-F12-MK-A2 |
| EAN | 4052568563141 |
| Zolltarifnummer | 85365019 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Seal material | EPDM |
| Series | SAMH |
| Protection rating | IP65 |
| Temperaturbereich | -20-60 °C |
| Temperature (max.) | 60 |
