This item joins components firmly and yet detachably and is listed as eye bolt M 10. Decisive here are working load limit, straight pull 230 kg and D M 10.
Ringschraube M 10, stainless steel A2 (DIN 580), working load limit, straight pull 230 kg
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€6.86
Item
FL-743311
Manufacturer no.
580-M10 ES
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.580-M10 ES
EAN4050571957674
Customs tariff number73181300
ConditionNew
Artikel
FL-743311
Frequently Bought Together
Listed as eye bolt M 10, this version joins components firmly and yet detachably. Relevant for the design are working load limit, straight pull 230 kg and D M 10. The stated material is stainless steel A2 (DIN 580).
Benefits
- working load limit, straight pull 230 kg
- D M 10
- defined head shape for a secure tool engagement, evidenced by D3 25 mm
- D1 25 mm
- D2 45 mm
- stated material stainless steel A2 (DIN 580)
Technical data
| material | stainless steel A2 (DIN 580) |
|---|---|
| D | M 10 |
| working load limit, straight pull [kg] | 230 |
| D1 [mm] | 25 |
| D2 [mm] | 45 |
| D3 [mm] | 25 |
| H [mm] | 45 |
| K [mm] | 10 |
| L [mm] | 17,0 |
Fields of application
The version is applied to assembly work in mechanical engineering, workshops and maintenance, here with D M 10.
Standards
Manufacture and dimensions follow DIN 580.
| Weight | 0.110000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | 580-M10 ES |
| EAN | 4050571957674 |
| Zolltarifnummer | 73181300 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Edelstahl A2 (DIN 580) |
| Norm | DIN 580 |
