Sandwich plate pressure relief valve ZDB10DP2-2X/200, size 10, 350 bar, 120 l/min, NBR, symbol P-T - Bosch Rexroth R901480281

Name: Sandwich plate pressure relief valve ZDB10DP2-2X/200, size 10, 350 bar, 120 l/min, NBR, symbol P-T - Bosch Rexroth R901480281
Brand: Bosch Rexroth
SKU: BRR-R901480281
Price: 194.45 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Pressure limiting in the valve stack to ISO 4401-05-04-0-05: ZDB10DP2-2X/200 for size 10, up to 350 bar and 120 l/min. Spool symbol P to T, manual setting, NBR seals, weight 2.68 kg.

Net

€194.45

excl. VAT

Item BRR-R901480281

Manufacturer no. R901480281

Question about this item

Datasheet (PDF) User manual 9 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The Bosch Rexroth sandwich plate pressure relief valve ZDB10DP2-2X/200 fits connection diagram ISO 4401-05-04-0-05 in size 10 and limits up to 350 bar at max. 120 l/min. Fitted between directional valve and subplate, ZDB10DP2-2X/200 limits pressure according to spool symbol P to T, with manual adjustment.

Benefits

Up to 350 bar: ZDB10DP2-2X/200 is rated for this maximum operating pressure.
120 l/min flow: maximum throughput in size 10.
Connection diagram ISO 4401-05-04-0-05: standardised interface for ZDB10DP2-2X/200.
Manual actuation: set pressure directly on the valve.
NBR seals: ZDB10DP2-2X/200 is suitable for hydraulic fluid HL, HLP, HLPD, HVLP, HVLPD, HFC.

Applications

Pressure protection in hydraulic power units, machine tools and presses, as original equipment or spare part. Material number R901480281 identifies ZDB10DP2-2X/200 unambiguously.

Technical data

Type	ZDB10DP2-2X/200
Material number	R901480281
Product type	Sandwich plate pressure relief valve
Size	10
Operating pressure (max.)	350 bar
Max. flow	120 l/min
Type of connection	Sandwich plate
Connection diagram	ISO 4401-05-04-0-05
Number of ports	4
Number of switching positions	2
Type of actuation	With manual actuation
Spool symbol	P to T
Seals	NBR
Hydraulic fluid	HL, HLP, HLPD, HVLP, HVLPD, HFC
Weight	2.68 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R901480281
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
Bauform	Zwischenplatte
Seal material	NBR
Function	Druckbegrenzung
Flow rate [l/min]	120
Norm	ISO 4401
Betriebsdruck max [bar]	350
