Logic cartridge valve LC16A00D7X/V size 16 320 l/min 420 bar FKM - Bosch Rexroth R901460048

Bosch Rexroth LC16A00D7X/V: size 16 logic cartridge valve with 420 bar operating pressure and a max. flow of 320 l/min. The valve is inserted into the NG 16 cartridge bore and piloted via a logic cover. According to the hydraulic symbol, the hydraulically actuated LC16A00D7X/V switches the oil flow direction.

Benefits

• High flow: max. 320 l/min
• Maximum operating pressure 420 bar
• Installation dimensions to ISO 7368, size 16
• Spool symbol A0D, 2 switching positions
• FKM seals for hydraulic fluids HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR
• Weight 0.2 kg

Applications

For control blocks with an NG 16 cartridge bore in stationary hydraulic systems, combined with a matching logic cover. Reorder using material number R901460048.
