When a pressure relief valve is replaced, the hole pattern of the subplate decides first. The pilot-operated DBW10A3-5X/350XS6SMG24K4B12 fits the subplate mounting to ISO 6264-06-09, limits from 4 to 350 bar in size 10 and handles up to 250 l/min at a weight of 4.88 kg.
Pressure Relief Valve DBW10A3-5X/350XS6SMG24K4B12 - Bosch Rexroth R901440305
BOSCH REXROTH
Original product
Net price (excl. VAT)
€2,090.29
Item
BRR-R901440305
Manufacturer no.
R901440305
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901440305
Country of originGermany
ConditionNew
Artikel
BRR-R901440305
Frequently Bought Together
-
This Item:
€2,090.29
-
Pressure Relief Valve DBDS20P1X/315 - Bosch Rexroth R900424278
€595.00
-
Pressure Relief Valve DBW10B2-5X/50XY6EG24N9K4 - Bosch Rexroth R900953347
€1,322.25
Total price
When a pressure relief valve is replaced, the hole pattern decides first. The pilot-operated DBW10A3-5X/350XS6SMG24K4B12 sits on the subplate mounting to ISO 6264-06-09 in size 10 and covers a setting range of 4 to 350 bar there with a relief flow of up to 250 l/min.
Benefits
- Subplate mounting to ISO 6264-06-09, two ports, no rework on existing size 10 plates
- Setting range 4 to 350 bar on a lockable rotary knob with scale
- Flow of up to 250 l/min at a maximum operating pressure of 350 bar
- Solenoid actuation at 24 VDC through a connector, 3-pole (2 + PE) according to EN 175301-803
- Weight of 4.88 kg, NBR seals matched to HL hydraulic fluid
Technical data
| Connection diagram | ISO 6264-06-09 |
| Max. flow | 250 l/min |
| Product family | DB.10-30 |
| Type of connection | Subplate mounting |
| Supply voltage | 24 VDC |
| Number of switching positions | 2 |
| Hydraulic fluid | HL |
| Number of ports | 2 |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Spool symbol | A |
| Operating pressure, max. | 350 bar |
| Size | 10 |
| Seals | NBR |
| Electrical connector | Connector, 3-pole (2 + PE) |
| Type of actuation | with solenoid actuation |
| Weight | 4.88 kg |
Application
The usual place is the pump outlet of a power unit where the circuit is capped at a fixed maximum. Because the valve is pilot-operated, the travel on the knob stays short even at 250 l/min. NBR seals together with HL hydraulic fluid define operation on mineral oil.
Manufacturer
Bosch Rexroth, material number R901440305, product family DB.10-30. Characteristic curves and installation dimensions are given in the data sheet Pressure relief valve (RE 25802), with a short version as RE 25802-B.
| Norm | DIN EN 175301-803, ISO 6264 |
|---|---|
| Hersteller-Nr | R901440305 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 4.880000 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
