Piped power units also work close to the system maximum these days. The DBW10BG2-5X/315-6EG24N9K4E is a threaded connection version adjustable up to 315 bar, discharges up to 200 l/min and unloads the pump through a built-on directional valve.
Pressure Relief Valve DBW10BG2-5X/315-6EG24N9K4E - Bosch Rexroth R901394533
BOSCH REXROTH
Original product
Net price (excl. VAT)
€1,548.45
Item
BRR-R901394533
Manufacturer no.
R901394533
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901394533
Country of originGermany
ConditionNew
Artikel
BRR-R901394533
Frequently Bought Together
-
This Item:
€1,548.45
-
Pressure Relief Valve DBW20B2-5X/100XY6EG24N9K4 - Bosch Rexroth R900915419
€1,391.21
-
Pressure Relief Valve DBW30B3N5X/100YU6EG24N9K4 - Bosch Rexroth R900764757
€1,848.57
Total price
An adjustment range of 4 to 315 bar reaches up towards the maximum operating pressure of 350 bar. The DBW10BG2-5X/315-6EG24N9K4E brings that range into a valve with a threaded connection and built-on solenoid unloading.
Benefits
- Adjustment range 4 to 315 bar, maximum operating pressure 350 bar.
- Threaded connection, installation without a manifold.
- Solenoid unloading via a built-on directional spool valve at 24 VDC.
- Up to 200 l/min flow, symbol B, two ports.
- Pressure valve in poppet seat design with an internal hexagon under a protective cap.
- 4.88 kg weight, NBR seals for HL hydraulic fluid.
Technical data
| Connection diagram | ISO 6264-06-09 |
| Max. flow | 200 l/min |
| Product family | DB.10-30 |
| Type of connection | Threaded connection |
| Conformity | CE |
| Supply voltage | 24 VDC |
| Number of switching positions | 2 |
| Hydraulic fluid | HL |
| Number of ports | 2 |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Spool symbol | B |
| Operating pressure, max. | 350 bar |
| Size | 10 |
| Seals | NBR |
| Electrical connector | Connector, 3-pole (2 + PE) |
| Type of actuation | with solenoid actuation |
| Weight | 4.88 kg |
Applications
The valve is used in presses, riveting equipment and clamping circuits operating in the upper pressure band. Unloading through the solenoid cuts power losses during holding phases. The protective cap secures the cracking pressure once it has been accepted.
Manufacturer
Bosch Rexroth, material number R901394533. Product family DB.10-30, connection diagram ISO 6264-06-09. Curves and tightening torques are listed in the manufacturer datasheet.
| Norm | DIN EN 175301-803, DIN EN ISO 228-1 |
|---|---|
| Hersteller-Nr | R901394533 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 4.880000 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
