Pressure transducer HM 20-2X/050-C-K35-N, 50 bar, 4 to 20 mA - Bosch Rexroth R901342022

Name: Pressure transducer HM 20-2X/050-C-K35-N, 50 bar, 4 to 20 mA - Bosch Rexroth R901342022
Brand: Bosch Rexroth
SKU: BRR-R901342022
Price: 197.50 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Pressure transducer HM 20-2X/050-C-K35-N for hydraulic systems up to 50 bar with 4 to 20 mA. Signal rise time below 1 ms for dynamic pressure control, excellent overload and burst behaviour. Supply 24 V DC, connection male thread G 1/4.

Net

€197.50

excl. VAT

Item BRR-R901342022

Manufacturer no. R901342022

Question about this item

Datasheet (PDF) User manual 5 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Bosch Rexroth pressure transducer HM 20-2X/050-C-K35-N is rated for max. 50 bar operating pressure and outputs its signal as 4 to 20 mA.

Benefits

Max. operating pressure 50 bar
Output signal: 4 to 20 mA
All wetted parts made of stainless steel
Signal rise time below 1 ms for dynamic pressure control
Excellent overload and burst behaviour

Application

Typically found in hydraulic power units and machine controls. Before installation, compare the connection (male thread G 1/4) and connector (connector, 4-pole, M12 x 1, coding A) with the system.

Technical data

Feature	Value
Product type	Pressure transducer
Type designation	HM 20-2X/050-C-K35-N
Operating pressure max.	50 bar
Output signal	4 to 20 mA
Supply voltage	24 V DC
Connection diagram	Male thread G 1/4
Electrical connection	Connector, 4-pole, M12 x 1, coding A
Seals	NBR
Hydraulic fluid	HL, HLP, HFC, nitrogen (up to 300 bar)
Conformity	UKCA - RoHS Directive SI2012/3032
Weight	0.07 kg
Material number	R901342022
Manufacturer	Bosch Rexroth
Hersteller-Nr	R901342022
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
Thread	G 1/4 AG
Seal material	NBR
Thread type	External thread
Norm	DIN EN 61076-2-101
Operating voltage	24 V DC
Betriebsdruck max [bar]	50
