When system pressure runs up towards 300 bar, this pilot operated size 32 seat valve covers an adjustment range of 2 to 315 bar. It limits flows of up to 650 l/min and weighs 6.95 kg with subplate mounting.
Pressure Relief Valve DBW30A2N5X/315YUS6EG24N9K4R12 - Bosch Rexroth R901311860
BOSCH REXROTH
Original product
Net price (excl. VAT)
€1,997.12
Item
BRR-R901311860
Manufacturer no.
R901311860
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901311860
Country of originGermany
ConditionNew
Artikel
BRR-R901311860
Frequently Bought Together
-
This Item:
€1,997.12
-
Pressure Relief Valve DBW30BG1N5X/200Y6EG24N9K4E - Bosch Rexroth R901120946
€1,858.80
-
Pressure Reducing Valve Z ZDR10DB2-5X/210YM - Bosch Rexroth R900443484
€386.94
Total price
The DBW30A2N5X/315YUS6EG24N9K4R12 limits pressure in circuits driven up towards 300 bar. The adjustment range runs from 2 to 315 bar, the maximum operating pressure is 350 bar at a flow capacity of 650 l/min.
Benefits
- Adjustment range 2 ... 315 bar also covers high pressure stages without a second valve.
- Seat valve design, giving low leakage in the closed state compared with spool type builds.
- Internal hexagon with protective cap for a secured pressure setting.
- Flow capacity of 650 l/min in size 32 at a weight of 6.95 kg.
- Subplate mounting with 2 ports to ISO 6264-10-17.
- Solenoid actuation at 24 VDC with a connector, 3-pole (2 + PE) to EN 175301-803.
Technical data
| Connection diagram | ISO 6264-10-17 |
| Max. flow | 650 l/min |
| Product family | DB.10-30 |
| Type of connection | Subplate mounting |
| Supply voltage | 24 VDC |
| Number of switching positions | 2 |
| Hydraulic fluid | HL |
| Number of ports | 2 |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Spool symbol | A |
| Operating pressure, max. | 350 bar |
| Size | 32 |
| Seals | NBR |
| Electrical connector | Connector, 3-pole (2 + PE) |
| Type of actuation | with solenoid actuation |
| Weight | 6.95 kg |
Application
The valve protects press circuits, clamping fixtures and test rigs working in the upper pressure band. The seat design keeps the circuit tight when closed, which matters during long holding periods under pressure. Subplate mounting to ISO 6264-10-17 allows installation on existing standard size 32 subplates.
Manufacturer
Bosch Rexroth, material number R901311860. Setting curves and installation notes are given in the data sheets Pressure relief valve (RE 25802) and Pressure relief valve (RE 25802-B).
| Norm | DIN EN 175301-803, ISO 6264 |
|---|---|
| Hersteller-Nr | R901311860 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 6.950000 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
