Pressure relief valve DBW10A1-5X/315-6EG24N9K4V solenoid actuation 24 V DC NG 10 subplate mounting - Bosch Rexroth R901298187

Name: Pressure relief valve DBW10A1-5X/315-6EG24N9K4V solenoid actuation 24 V DC NG 10 subplate mounting - Bosch Rexroth R901298187
Brand: Bosch Rexroth
SKU: BRR-R901298187
Price: 1454.47 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

The DBW10A1-5X/315-6EG24N9K4V limits circuit pressure to the set value, with the function switched by a 24 V DC solenoid. Up to 350 bar and 250 l/min, size NG 10, subplate mounting, FKM seals. Genuine Bosch Rexroth part R901298187, 4.6 kg.

Net

€1,454.47

excl. VAT

Item BRR-R901298187

Manufacturer no. R901298187

Question about this item

Datasheet (PDF) User manual 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

DBW10A1-5X/315-6EG24N9K4V is a Bosch Rexroth pressure relief valve with 24 V DC solenoid actuation, size NG 10. The DBW10A1-5X/315-6EG24N9K4V operates up to 350 bar and passes up to 250 l/min. Bosch Rexroth describes the DBW10A1-5X/315-6EG24N9K4V as an industrial hydraulic valve for the high performance range.

Benefits

Subplate mounting with ISO 6264-06-09 porting pattern: replace the valve without disconnecting the pipework
Rated for a maximum operating pressure of 350 bar
Flow rate up to 250 l/min
24 V DC solenoid, connected via connector, 3-pole (2 + PE) according to EN 175301-803
FKM seals (code letter V in the type)

Applications

Suitable as system pressure limitation or safety valve in the circuit, the DBW10A1-5X/315-6EG24N9K4V is designed for subplate mounting to porting pattern ISO 6264-06-09. The DBW10A1-5X/315-6EG24N9K4V is intended for the hydraulic fluids HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR. Genuine Bosch Rexroth part, material number R901298187.

Technical data

Type	DBW10A1-5X/315-6EG24N9K4V
Material number	R901298187
Product type	Pressure relief valve with solenoid actuation
Size	NG 10
Type of connection	Subplate mounting
Connection diagram	ISO 6264-06-09
Type of actuation	with solenoid actuation
Spool symbol	A
Number of switching positions	2
Number of ports	2
Operating pressure max.	350 bar
Max. flow	250 l/min
Seals	FKM
Hydraulic fluid	HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR
Supply voltage	24 V DC
Electrical connector	Connector, 3-pole (2 + PE)
Electrical connection	Connector, 3-pole (2 + PE) according to EN 175301-803
Weight	4.6 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R901298187
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
Bauform	Plattenaufbau
Seal material	FKM
Function	Druckbegrenzung
Actuation type	Electrical
Norm	DIN EN 175301-803, ISO 6264
Operating voltage	24 V DC
Betriebsdruck max [bar]	350
