Pressure Relief Valve DBDS6G1X/315VE - Bosch Rexroth R901278284

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Pressure relief valve DBDS6G1X/315VE pipe thread G1/4 NG 6 max. 315 bar FKM - Bosch Rexroth R901278284

Name: Pressure relief valve DBDS6G1X/315VE pipe thread G1/4 NG 6 max. 315 bar FKM - Bosch Rexroth R901278284
Brand: Bosch Rexroth
SKU: BRR-R901278284
Price: 547.70 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

The Bosch Rexroth DBDS6G1X/315VE keeps pressure below the set value, excess oil flows from P to T back to tank. Size NG 6, pipe thread G1/4, 315 bar max. operating pressure at up to 52 l/min, FKM seals. Genuine Bosch Rexroth part, material number R901278284, weight 1.7 kg.

Net

€547.70

excl. VAT

Item BRR-R901278284

Manufacturer no. R901278284

Question about this item

Datasheet (PDF) User manual 12 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The DBDS6G1X/315VE pressure relief valve (NG 6) limits the highest pressure in the circuit to a set value. According to the manufacturer it handles 315 bar operating pressure and 52 l/min flow.

Benefits

G1/4 pipe thread to ISO 228-1 for direct in-line installation
Rated for 315 bar max. operating pressure
Flow rate up to 52 l/min
Flow path P to T: excess oil returns directly to tank
Mechanical actuation, set directly on the valve
FKM seals

Applications

Suited as a safety valve in the circuit, design: pipe thread G1/4. Genuine Bosch Rexroth part, material number R901278284.

Technical data

Type	DBDS6G1X/315VE
Material number	R901278284
Product type	Pressure relief valve
Size	NG 6
Type of connection	Threaded connection
Connection diagram	Pipe thread G1/4 ISO 228-1
Type of actuation	with mechanical actuation
Spool symbol	P to T
Number of switching positions	2
Number of ports	2
Operating pressure max.	315 bar
Max. flow	52 l/min
Seals	FKM
Hydraulic fluid	HL, HLP
Conformity	CE
Weight	1.7 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R901278284
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
Ausführung	Gewindeanschluss NG6
Bauform	Gewindeanschluss
Thread	G 1/4
Seal material	FKM
Function	Druckbegrenzung
Thread standard	DIN EN ISO 228-1
Actuation type	Mechanical
Norm	DIN EN ISO 228-1
Betriebsdruck max [bar]	315
