Logic cover LFA32E-7X/CA40DQMG24FV for 2-way cartridge valves size 32, 420 bar, FKM seals - Bosch Rexroth R901270144

Name: Logic cover LFA32E-7X/CA40DQMG24FV for 2-way cartridge valves size 32, 420 bar, FKM seals - Bosch Rexroth R901270144
Brand: Bosch Rexroth
SKU: BRR-R901270144
Price: 1576.24 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Up to 420 bar and 1120 l/min: logic cover LFA32E-7X/CA40DQMG24FV for cartridge valves in size 32 to ISO 7368. Spool symbol A to B, B to A, 24 V DC, FKM seals, material number R901270144, weight 6.4 kg.

Net

€1,576.24

excl. VAT

Item BRR-R901270144

Manufacturer no. R901270144

Question about this item

Datasheet (PDF) User manual 4 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

For 2-way cartridge valves in size 32, Bosch Rexroth supplies the logic cover LFA32E-7X/CA40DQMG24FV, rated up to 420 bar at max. 1120 l/min. LFA32E-7X/CA40DQMG24FV sits as a control cover on the 2-way cartridge valve, closes the ISO 7368 cavity and enables flow A to B, B to A.

Benefits

420 bar: maximum operating pressure of LFA32E-7X/CA40DQMG24FV according to the manufacturer.
1120 l/min flow: maximum throughput in size 32.
Connection diagram ISO 7368: LFA32E-7X/CA40DQMG24FV fits standardised cavities in size 32.
FKM seals: LFA32E-7X/CA40DQMG24FV is suitable for hydraulic fluid HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR.

Applications

Hydraulic manifolds with cartridge valves in size 32, for example on presses and large systems. To replace an existing LFA32E-7X/CA40DQMG24FV, material number R901270144 is all you need.

Technical data

Type	LFA32E-7X/CA40DQMG24FV
Material number	R901270144
Product type	Control cover for 2-way cartridge valves
Size	32
Operating pressure (max.)	420 bar
Max. flow	1120 l/min
Type of connection	Subplate mounting
Connection diagram	ISO 7368
Number of ports	2
Number of switching positions	2
Spool symbol	A to B, B to A
Supply voltage	24 V DC
Seals	FKM
Hydraulic fluid	HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR
Weight	6.4 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R901270144
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
Bauform	Plattenaufbau
Seal material	FKM
Norm	DIN EN 61076-2-101, ISO 7368
Operating voltage	24 V DC
Betriebsdruck max [bar]	420
