Pressure relief valve DBW20B3-5X/200X6EG24N9K4 solenoid actuation 24 V DC NG 25 subplate mounting - Bosch Rexroth R901197366

Name: Pressure relief valve DBW20B3-5X/200X6EG24N9K4 solenoid actuation 24 V DC NG 25 subplate mounting - Bosch Rexroth R901197366
Brand: Bosch Rexroth
SKU: BRR-R901197366
Price: 1578.77 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Electrically switchable pressure limitation: the Bosch Rexroth DBW20B3-5X/200X6EG24N9K4 limits system pressure and is actuated by a 24 V DC solenoid. Up to 350 bar and 500 l/min, size NG 25, subplate mounting, NBR seals. Material number R901197366, weight 5.35 kg, genuine Bosch Rexroth.

Net

€1,578.77

excl. VAT

Item BRR-R901197366

Manufacturer no. R901197366

Question about this item

Datasheet (PDF) User manual 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The DBW20B3-5X/200X6EG24N9K4 pressure relief valve in size NG 25 limits the highest pressure in the circuit and is switched by a 24 V DC solenoid. The DBW20B3-5X/200X6EG24N9K4 operates up to 350 bar and passes up to 500 l/min. Bosch Rexroth describes the DBW20B3-5X/200X6EG24N9K4 as an industrial hydraulic valve for the high performance range.

Benefits

Mounts on a subplate with ISO 6264-08-13 porting pattern, pipework stays untouched when changing the valve
Rated for a maximum operating pressure of 350 bar
Up to 500 l/min flow
24 V DC solenoid, connected via connector, 3-pole (2 + PE) according to EN 175301-803
NBR seals

Applications

Used as a safety or system pressure valve in industrial hydraulics, the DBW20B3-5X/200X6EG24N9K4 is designed for subplate mounting to porting pattern ISO 6264-08-13. The DBW20B3-5X/200X6EG24N9K4 is intended for the hydraulic fluids HL, HLP, HLPD, HVLP, HVLPD, HFC. Genuine Bosch Rexroth part, material number R901197366.

Technical data

Type	DBW20B3-5X/200X6EG24N9K4
Material number	R901197366
Product type	Pressure relief valve with solenoid actuation
Size	NG 25
Type of connection	Subplate mounting
Connection diagram	ISO 6264-08-13
Type of actuation	with solenoid actuation
Spool symbol	B
Number of switching positions	2
Number of ports	2
Operating pressure max.	350 bar
Max. flow	500 l/min
Seals	NBR
Hydraulic fluid	HL, HLP, HLPD, HVLP, HVLPD, HFC
Supply voltage	24 V DC
Electrical connector	Connector, 3-pole (2 + PE)
Electrical connection	Connector, 3-pole (2 + PE) according to EN 175301-803
Weight	5.35 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R901197366
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
Bauform	Plattenaufbau
Seal material	NBR
Function	Druckbegrenzung
Actuation type	Electrical
Norm	DIN EN 175301-803, ISO 6264
Operating voltage	24 V DC
Betriebsdruck max [bar]	350

Downloads

Datasheet

Datasheet (PDF) PDF
Pressure relief valve (RE 25802) PDF, 1.1 MB, 24 p. EN
Druckbegrenzungsventil, vorgesteuert (RD 25802) PDF, 1.1 MB, 24 p. DE

User Manual

Pressure relief valve (RE 25802-B) PDF, 1.4 MB, 56 p. EN
Betriebsanleitung RD25802-B/10.21 09.19 Druckbegrenzungsventil, vorgesteuert (Sicherheitsventil nach (RD 25802) PDF, 1.4 MB, 56 p. DE
Notice d'utilisation Réf. article. R901557687 Limiteur de pression, piloté (Soupape de sûreté confor (RF 25802) PDF, 1.4 MB, 56 p. FR
