For power units with a variable-speed drive, this size 200 internal gear pump delivers up to 600 l/min at a maximum operating pressure of 170 bar. The shaft end is a geared 38-4 shaft to ISO 3019-1, the pump weighs 56.3 kg and includes a through-drive.
Internal Gear Pump PGH5-3X/200RR07VU2 - Bosch Rexroth R901147134
BOSCH REXROTH
Original product
Net price (excl. VAT)
€6,521.91
Item
BRR-R901147134
Manufacturer no.
R901147134
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901147134
Country of originGermany
ConditionNew
Artikel
BRR-R901147134
Frequently Bought Together
-
This Item:
€6,521.91
-
Internal Gear Pump PGH5-3X/080RE11VE4 - Bosch Rexroth R901147123
€4,548.64
-
Internal Gear Pump PGH2-2X/005RR07WU2 - Bosch Rexroth R901248441
€1,252.05
Total price
PGH5-3X/200RR07VU2 works with constant displacement in an open circuit and is designed for speed-controlled drives because it delivers with low pulsation across the whole speed range. The geared 38-4, 17T 12/24 DP shaft couples it directly to motors with inch-pitch splines.
Advantages
- Geared 38-4, 17T 12/24 DP shaft to ISO 3019-1 for mounting on motors with inch-pitch splines
- 2-hole mounting flange 127-2 to ISO 3019-1
- 600 l/min maximum flow at 170 bar maximum operating pressure
- Usable with special fluids up to 115 bar operating pressure
- Through-drive fitted, so a second pump can be built on behind this one
- Clockwise rotation, cast housing for HLP fluid, FKM seals, 56.3 kg mass
Technical data
| Direction of rotation | clockwise rotation |
| Operating pressure max. special fluids | 115 bar |
| Displacement type | constant |
| Max. flow | 600 l/min |
| Product family | PGH |
| Through-drive | with |
| Hydraulic fluid | HLP |
| Shaft end | Geared 38-4, 17T 12/24 DP, ISO 3019-1 |
| Fastening | 2-hole mounting flange 127-2, ISO 3019-1 |
| Operating pressure, max. | 170 bar |
| Size | 200 |
| Seals | FKM |
| Mounting flange | 2-hole mounting flange 127-2 according to ISO 3019-1 |
| Weight | 56.3 kg |
Application
The pump sits in power units for machine tools, presses and test rigs where the motor sets the delivery through its speed rather than through a flow control valve. Because the displacement stays constant, delivery is directly proportional to speed and therefore simple to calculate. The through-drive allows a second circuit without a second motor.
Manufacturer
Bosch Rexroth, material number R901147134.
| Norm | ISO 3019-1 |
|---|---|
| Hersteller-Nr | R901147134 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 56.296000 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
