Pressure switch HED 8 OP-2X/350K14S, pressure stage 350 bar, subplate mounting - Bosch Rexroth R901102365

Pressure switch HED 8 OP-2X/350K14S for pressure monitoring in hydraulic circuits up to 400 bar, supply voltage 12 to 250 V AC/DC.

Benefits

• Max. operating pressure 400 bar
• Pressure stage 350 bar as per type designation
• Output signal: microswitch with NC/NO function
• Potential-free switching of currents from 1 mA to 2.0 A
• Repeatability better than 1% of the set pressure
• Small hysteresis depending on the set switching point

Application

For clamping hydraulics, presses and power units where a pressure value has to be reported or passed to the control as a signal. Hydraulic fluid as per manufacturer: HL, HLP, HLPD, HVLP, HVLPD.
