Pressure relief valve DBDS30P1X/200E subplate mounting NG 30 max. 200 bar - Bosch Rexroth R901013633

Name: Pressure relief valve DBDS30P1X/200E subplate mounting NG 30 max. 200 bar - Bosch Rexroth R901013633
Brand: Bosch Rexroth
SKU: BRR-R901013633
Price: 1253.55 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Overload protection for the hydraulic circuit: the DBDS30P1X/200E valve opens at the set pressure and diverts the excess flow from P to T. Size NG 30, as a subplate-mounted valve, up to 200 bar and 302 l/min, NBR seals. Genuine Bosch Rexroth part, material number R901013633, weight 15.65 kg.

Net

€1,253.55

excl. VAT

Item BRR-R901013633

Manufacturer no. R901013633

Question about this item

Datasheet (PDF) User manual 12 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The DBDS30P1X/200E pressure relief valve in size NG 30 protects pumps, lines and consumers against excessive pressure. Operating pressure reaches 200 bar, flow up to 302 l/min.

Benefits

Subplate mounting NG30: valve can be replaced without disconnecting the pipework
Operating pressure up to 200 bar
Flow rate up to 302 l/min
Flow path P to T: excess oil returns directly to tank
NBR seals

Applications

Used as a safety or system pressure valve in industrial hydraulics, version subplate mounting. Genuine Bosch Rexroth part, material number R901013633.

Technical data

Type	DBDS30P1X/200E
Material number	R901013633
Product type	Pressure relief valve
Size	NG 30
Type of connection	Subplate mounting
Connection diagram	Subplate mounting NG30
Type of actuation	with mechanical actuation
Spool symbol	P to T
Number of switching positions	2
Number of ports	2
Operating pressure max.	200 bar
Max. flow	302 l/min
Seals	NBR
Hydraulic fluid	HL, HLP
Conformity	CE
Weight	15.65 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R901013633
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
Bauform	Plattenaufbau
Seal material	NBR
Function	Druckbegrenzung
Actuation type	Mechanical
Betriebsdruck max [bar]	200
