Screw-in cartridge pressure relief valve DBDH10K1X/440E NG 10 max. 440 bar NBR - Bosch Rexroth R901011982

The DBDH10K1X/440E pressure relief valve in size NG 10 protects pumps, lines and consumers against excessive pressure. It is rated for up to 440 bar operating pressure at a maximum of 140 l/min.

Benefits

• Screw-in cartridge for mounting cavity DBD NG10, space-saving inside the manifold block
• Rated for 440 bar max. operating pressure
• Handles up to 140 l/min
• Relief from P to T keeps the circuit below the set pressure
• Mechanically actuated, no electrical connection needed
• NBR seals

Applications

Typical use is protecting pumps and sub-circuits in hydraulic blocks, here as screw-in cartridge NG 10. Genuine Bosch Rexroth part, material number R901011982.
