Anyone who changes the system pressure regularly needs a setting that can be read and locked. The DBW30B3-5X/315-6SMG24N9K4 has a lockable rotary knob with a scale and works in a range from 4 to 315 bar at up to 650 l/min.
Pressure Relief Valve DBW30B3-5X/315-6SMG24N9K4 - Bosch Rexroth R900960980
BOSCH REXROTH
Original product
Net price (excl. VAT)
€2,068.82
Item
BRR-R900960980
Manufacturer no.
R900960980
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R900960980
Country of originGermany
ConditionNew
Artikel
BRR-R900960980
Frequently Bought Together
-
This Item:
€2,068.82
-
Pressure Relief Valve DBWC10A3-5X/315-6EG24N9K4 - Bosch Rexroth R900755283
€1,356.73
-
Pressure Relief Valve DBW10B2-5X/315-6SMG24N9K4V - Bosch Rexroth R900952223
€1,728.00
Total price
A scale on the knob makes the set pressure readable, the lock keeps unauthorised hands off it. The DBW30B3-5X/315-6SMG24N9K4 combines both, and its range runs from 4 to 315 bar.
Benefits
- Lockable rotary knob with scale for a repeatable setting
- Pressure setting range 4 to 315 bar, operating pressure up to 350 bar
- Up to 650 l/min in size 32, porting pattern ISO 6264-10-17
- Pilot-operated seat valve, symbol B, two switching positions
- NBR seals for HL hydraulic fluid, weight 6.49 kg
- 24 V DC solenoid, 3-pole connector (2 + PE) to EN 175301-803
Technical data
| Connection diagram | ISO 6264-10-17 |
| Max. flow | 650 l/min |
| Product family | DB.10-30 |
| Type of connection | Subplate mounting |
| Supply voltage | 24 VDC |
| Number of switching positions | 2 |
| Hydraulic fluid | HL |
| Number of ports | 2 |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Spool symbol | B |
| Operating pressure, max. | 350 bar |
| Size | 32 |
| Seals | NBR |
| Electrical connector | Connector, 3-pole (2 + PE) |
| Type of actuation | with solenoid actuation |
| Weight | 6.49 kg |
Application
In test rigs and production lines with changing workpieces the pressure is adjusted more often. The scale allows a value found earlier to be dialled in again directly. Once the batch is set up, the lock secures the value against drift.
Manufacturer
Bosch Rexroth, material number R900960980. The curves of the setting range are shown in data sheet RE 25802, further reading in RE 25802-B.
| Norm | DIN EN 175301-803, ISO 6264 |
|---|---|
| Hersteller-Nr | R900960980 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 6.481000 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
