Logic cartridge valve LC16A10D7X/V size 16 320 l/min 420 bar FKM - Bosch Rexroth R900946786

The Bosch Rexroth logic cartridge valve LC16A10D7X/V is rated for size 16, 420 bar operating pressure and a max. flow of 320 l/min. It is inserted into the NG 16 cartridge bore of a control block and receives its function from the control cover on top. The LC16A10D7X/V switches the oil flow direction according to the hydraulic symbol and is hydraulically actuated.

Benefits

• Up to 320 l/min flow at NG 16
• Operating pressure up to 420 bar
• Installation dimensions to ISO 7368, size 16
• Spool symbol A10D, 2 switching positions
• FKM seals for hydraulic fluids HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR
• Weight 0.21 kg

Applications

For control blocks with an NG 16 cartridge bore in stationary hydraulic systems, combined with a matching logic cover. Reorder using material number R900946786.
