Pressure relief valve DBW15BG2-5X/100-6EG24N9K4 solenoid actuation 24 V DC NG 16 threaded connection - Bosch Rexroth R900929085

Name: Pressure relief valve DBW15BG2-5X/100-6EG24N9K4 solenoid actuation 24 V DC NG 16 threaded connection - Bosch Rexroth R900929085
Brand: Bosch Rexroth
SKU: BRR-R900929085
Price: 1391.21 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

The DBW15BG2-5X/100-6EG24N9K4 limits circuit pressure to the set value, with the function switched by a 24 V DC solenoid. Up to 350 bar and 500 l/min, size NG 16, threaded connection, NBR seals. Genuine Bosch Rexroth part R900929085, 6.88 kg.

Net

€1,391.21

excl. VAT

Item BRR-R900929085

Manufacturer no. R900929085

Question about this item

Datasheet (PDF) User manual 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The DBW15BG2-5X/100-6EG24N9K4 pressure relief valve in size NG 16 limits the highest pressure in the circuit and is switched by a 24 V DC solenoid. Operating pressure of the DBW15BG2-5X/100-6EG24N9K4 reaches 350 bar, flow up to 500 l/min. Bosch Rexroth describes the DBW15BG2-5X/100-6EG24N9K4 as an industrial hydraulic valve for the high performance range.

Benefits

In-line installation via threaded connection, size NG 16
Operating pressure up to 350 bar
Flow rate up to 500 l/min
24 V DC solenoid, connected via connector, 3-pole (2 + PE) according to EN 175301-803
NBR seals

Applications

Used as a safety or system pressure valve in industrial hydraulics, the DBW15BG2-5X/100-6EG24N9K4 is built with a threaded connection. Approved hydraulic fluids for the DBW15BG2-5X/100-6EG24N9K4: HL, HLP, HLPD, HVLP, HVLPD, HFC. Genuine Bosch Rexroth part, material number R900929085.

Technical data

Type	DBW15BG2-5X/100-6EG24N9K4
Material number	R900929085
Product type	Pressure relief valve with solenoid actuation
Size	NG 16
Type of connection	Threaded connection
Connection diagram	Pipe thread according to ISO 228-1
Type of actuation	with solenoid actuation
Spool symbol	B
Number of switching positions	2
Number of ports	2
Operating pressure max.	350 bar
Max. flow	500 l/min
Seals	NBR
Hydraulic fluid	HL, HLP, HLPD, HVLP, HVLPD, HFC
Supply voltage	24 V DC
Electrical connector	Connector, 3-pole (2 + PE)
Electrical connection	Connector, 3-pole (2 + PE) according to EN 175301-803
Weight	6.88 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R900929085
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
Bauform	Gewindeanschluss
Seal material	NBR
Function	Druckbegrenzung
Thread standard	DIN EN ISO 228-1
Actuation type	Electrical
Norm	DIN EN 175301-803, DIN EN ISO 228-1
Operating voltage	24 V DC
Betriebsdruck max [bar]	350
