Logic cover with stroke limiter LFA32H2-7X/F size 32 up to 420 bar NBR - Bosch Rexroth R900912728

The Bosch Rexroth logic cover LFA32H2-7X/F turns a size 32 2-way cartridge valve into a working valve stage for pressures up to 420 bar. Sealed with NBR, the cover closes the size 32 cartridge bore and routes the control channels to the cartridge valve. Manual stroke limitation on the LFA32H2-7X/F restricts the opening stroke of the cartridge valve, so the flow can be adapted.

Benefits

• Operating pressure up to 420 bar
• Standardised ISO 7368 connection diagram for size 32 cartridge bores
• Spool symbol H for the switching function per hydraulic symbol
• NBR seals for hydraulic fluids HL, HLP, HLPD, HVLP, HVLPD, HFC
• Manual stroke limitation for the opening stroke of the cartridge valve
• Subplate mounting directly on the control block, weight 5.4 kg

Applications

Used in control blocks with NG 32 logic cartridge valves, as a replacement or for new builds. Order reference: material number R900912728, type LFA32H2-7X/F.
