Logic cartridge valve LC32A40D7X/ size 32 1130 l/min 420 bar NBR - Bosch Rexroth R900909665

With LC32A40D7X/, Bosch Rexroth supplies a size 32 2-way logic cartridge valve for up to 420 bar and a max. flow of 1130 l/min. As a cartridge valve it sits directly in the NG 32 bore, the control cover above defines how it is piloted. Hydraulically actuated, the LC32A40D7X/ switches the oil flow direction as shown in the hydraulic symbol.

Benefits

• Up to 1130 l/min flow at NG 32
• Rated for operating pressures up to 420 bar
• Standardised cartridge bore to ISO 7368
• Spool symbol A40D, 2 switching positions
• NBR seals for hydraulic fluids HL, HLP, HLPD, HVLP, HVLPD, HFC
• Weight 1.1 kg

Applications

Used in size 32 logic control blocks, as a replacement or for new builds. Order reference: material number R900909665, type LC32A40D7X/.
