Logic cartridge valve LC32A05D7X/ size 32 1130 l/min 420 bar NBR - Bosch Rexroth R900909245

Bosch Rexroth LC32A05D7X/: size 32 2-way logic cartridge valve with 420 bar operating pressure and a max. flow of 1130 l/min. The valve is inserted into the NG 32 cartridge bore and piloted via a logic cover. According to the hydraulic symbol, the hydraulically actuated LC32A05D7X/ switches the oil flow direction.

Benefits

• High flow: max. 1130 l/min
• Maximum operating pressure 420 bar
• ISO 7368 connection diagram for the NG 32 cartridge bore
• Spool symbol A5D, 2 switching positions
• NBR seals for hydraulic fluids HL, HLP, HLPD, HVLP, HVLPD, HFC
• Weight 0.99 kg

Applications

The valve is used in control blocks with an NG 32 cartridge bore, also as a spare part for the identical type LC32A05D7X/. Material number R900909245.
