With pressure stage 315 this build sits one step below the top of the series. The DBW30B3-5X/315-6EG24N9K4V protects circuits carrying up to 650 l/min and switches the unloading function electrically from 24 VDC.
Pressure Relief Valve DBW30B3-5X/315-6EG24N9K4V - Bosch Rexroth R900786641
BOSCH REXROTH
Original product
Net price (excl. VAT)
€2,002.18
Item
BRR-R900786641
Manufacturer no.
R900786641
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R900786641
Country of originGermany
ConditionNew
Artikel
BRR-R900786641
Frequently Bought Together
-
This Item:
€2,002.18
-
Pressure Relief Valve DBW10AG2-5X/200-6EG24N9K4 - Bosch Rexroth R900929092
€1,322.25
-
Pressure Relief Valve DBDS10P1X/200 - Bosch Rexroth R900424157
€414.87
Total price
This build of the DBW series is marked with pressure stage 315 and is intended for plants whose working pressure lies below it. In size 32 it limits pressure at flow up to 650 l/min and vents the circuit through the mounted directional valve.
Benefits
- Pressure stage 315 in the type code DBW30B3-5X/315.
- Flow up to 650 l/min, maximum operating pressure 350 bar.
- Electrical unloading from 24 VDC, spool symbol B.
- Subplate mounting to ISO 6264-10-17 in size 32.
- FKM seals, HL hydraulic fluid.
- Two switching positions on two ports, weight 6.49 kg.
Technical data
| Connection diagram | ISO 6264-10-17 |
| Max. flow | 650 l/min |
| Product family | DB.10-30 |
| Type of connection | Subplate mounting |
| Supply voltage | 24 VDC |
| Number of switching positions | 2 |
| Hydraulic fluid | HL |
| Number of ports | 2 |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Spool symbol | B |
| Operating pressure, max. | 350 bar |
| Size | 32 |
| Seals | FKM |
| Electrical connector | Connector, 3-pole (2 + PE) |
| Type of actuation | with solenoid actuation |
| Weight | 6.49 kg |
Application
The build suits power units whose working pressure sits around 300 bar and which still need the full flow capacity of size 32. Subplate mounting allows installation in existing manifolds without changing the piping.
Manufacturer
The Bosch Rexroth material number is R900786641. The setting range of pressure stage 315, the characteristic curves and the port dimensions are documented in the pressure relief valve data sheet RE 25802 and in RE 25802-B.
| Norm | DIN EN 175301-803, ISO 6264 |
|---|---|
| Hersteller-Nr | R900786641 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 6.490000 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
