Pressure relief valve DBDS10G1X/200E pipe thread G1/2 NG 10 max. 200 bar NBR - Bosch Rexroth R900769540

DBDS10G1X/200E is a mechanically actuated Bosch Rexroth pressure relief valve in size NG 10 with flow path P to T. It is rated for up to 200 bar operating pressure at a maximum of 140 l/min.

Benefits

• G1/2 pipe thread to ISO 228-1 for direct in-line installation
• Rated for 200 bar max. operating pressure
• Handles up to 140 l/min
• Relief from P to T keeps the circuit below the set pressure
• Mechanically actuated, no electrical connection needed
• NBR seals

Applications

Used as a safety valve or for system pressure limitation, version pipe thread G1/2. Genuine Bosch Rexroth part, material number R900769540.
