Logic cartridge valve LC50A40E7X/V size 50 3500 l/min 420 bar FKM - Bosch Rexroth R900710125

Bosch Rexroth LC50A40E7X/V: size 50 logic cartridge valve with 420 bar operating pressure and a max. flow of 3500 l/min. The valve is inserted into the NG 50 cartridge bore and piloted via a logic cover. According to the hydraulic symbol, the hydraulically actuated LC50A40E7X/V switches the oil flow direction.

Benefits

• High flow: max. 3500 l/min
• Maximum operating pressure 420 bar
• ISO 7368 connection diagram for the NG 50 cartridge bore
• Spool symbol A40E, 2 switching positions
• FKM seals for hydraulic fluids HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR
• Weight 3.04 kg

Applications

The valve is used in control blocks with an NG 50 cartridge bore, also as a spare part for the identical type LC50A40E7X/V. Material number R900710125.
