Logic cartridge valve LC100A40E6X/ size 100 11500 l/min 420 bar NBR - Bosch Rexroth R900525698

With LC100A40E6X/, Bosch Rexroth supplies a size 100 logic cartridge valve for up to 420 bar and a max. flow of 11500 l/min. As a cartridge valve it sits directly in the NG 100 bore, the control cover above defines how it is piloted. Hydraulically actuated, the LC100A40E6X/ switches the oil flow direction as shown in the hydraulic symbol.

Benefits

• High flow: max. 11500 l/min
• Rated for operating pressures up to 420 bar
• ISO 7368 connection diagram for the NG 100 cartridge bore
• Spool symbol A40E, 2 switching positions
• NBR seals for hydraulic fluids HL, HLP, HLPD, HVLP, HVLPD, HFC
• Weight 24.39 kg

Applications

The valve is used in control blocks with an NG 100 cartridge bore, also as a spare part for the identical type LC100A40E6X/. Material number R900525698.
