Sandwich plate pressure relief valve ZDB6VP2-4X/200V, size 6, 315 bar, 60 l/min, FKM, symbol P-T - Bosch Rexroth R900409844

Name: Sandwich plate pressure relief valve ZDB6VP2-4X/200V, size 6, 315 bar, 60 l/min, FKM, symbol P-T - Bosch Rexroth R900409844
Brand: Bosch Rexroth
SKU: BRR-R900409844
Price: 268.93 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Sandwich plate pressure relief valve ZDB6VP2-4X/200V limits pressure directly in the valve stack, no extra block needed. Up to 315 bar and 60 l/min, size 6, connection diagram ISO 4401-03-02-0-05, spool symbol P to T, FKM seals, weight 1.16 kg.

Net

€268.93

excl. VAT

Item BRR-R900409844

Manufacturer no. R900409844

Question about this item

Datasheet (PDF) User manual 8 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The Bosch Rexroth sandwich plate pressure relief valve ZDB6VP2-4X/200V fits connection diagram ISO 4401-03-02-0-05 in size 6 and limits up to 315 bar at max. 60 l/min. Fitted between directional valve and subplate, ZDB6VP2-4X/200V limits pressure according to spool symbol P to T, with manual adjustment.

Benefits

Up to 315 bar: ZDB6VP2-4X/200V is rated for this maximum operating pressure.
60 l/min flow: maximum throughput in size 6.
Connection diagram ISO 4401-03-02-0-05: standardised interface for ZDB6VP2-4X/200V.
Manual actuation: set pressure directly on the valve.
FKM seals: ZDB6VP2-4X/200V is suitable for hydraulic fluid HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR.

Applications

Protection of pumps, cylinders and hydraulic motors in industrial hydraulics. For replacement orders, type ZDB6VP2-4X/200V and material number R900409844 allow a reliable match with the existing valve.

Technical data

Type	ZDB6VP2-4X/200V
Material number	R900409844
Product type	Sandwich plate pressure relief valve
Size	6
Operating pressure (max.)	315 bar
Max. flow	60 l/min
Type of connection	Sandwich plate
Connection diagram	ISO 4401-03-02-0-05
Number of ports	4
Number of switching positions	2
Type of actuation	With manual actuation
Spool symbol	P to T
Seals	FKM
Hydraulic fluid	HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR
Weight	1.16 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R900409844
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
Bauform	Zwischenplatte
Seal material	FKM
Function	Druckbegrenzung
Flow rate [l/min]	60
Norm	ISO 4401
Betriebsdruck max [bar]	315
