Repair kit for SQN series compact cylinders, 20 mm bore - E.MC

Small compact cylinders often run at the pace of fixtures and wear first at the sealing points. This repair kit fits SQN series cylinders with a 20 mm bore, recognisable by the M5 port and the M5x0.8 piston rod thread.

Advantages

• Fits compact cylinders with 20 mm bore
• Barrel, covers and piston rod are reused
• For cylinders rated 1 to 10 bar per E.MC datasheet
• Clear matching by 20 mm bore and M5 cylinder port

Applications

• Overhauling leaking cylinders in the workshop
• Preventive part replacement at service intervals
• Spares stock for machines with 20 mm bore compact cylinders

Accessories and spare parts

The kit fits all double-acting compact cylinders with magnetic piston and 20 mm bore in this range, whatever the stroke.
