ISOLine ISO 15552 tie-rod cylinder, double-acting, 80 mm bore, 900 mm stroke, G3/8, magnetic piston - Norgren RA/802080/M/900/M/H/703

Norgren ✓ Original product Brand new

With an 80 mm bore and 900 mm stroke, this double-acting tie-rod cylinder produces a theoretical 3016 N at 6 bar. Mounting dimensions of the RA/802080/M/900/M/H/703 follow ISO 15552 and VDMA 24562, the port is G3/8.

Net
€621.47
excl. VAT
Item NRG-RA/802080/M/900/M/H/703
Manufacturer no. RA/802080/M/900/M/H/703
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

A theoretical 3016 N at 6 bar and 900 mm of stroke: the Norgren RA/802080/M/900/M/H/703 with 80 mm bore is a double-acting tie-rod cylinder from the ISOLine range.

Benefits

  • Mounting dimensions of the RA/802080/M/900/M/H/703 follow ISO 15552 and VDMA 24562.
  • Cylinder switches pick up any position via the magnetic piston on 900 mm of stroke with an 80 mm bore.
  • The RA/802080/M/900/M/H/703 operates at 1 to 16 bar.
  • On the RA/802080/M/900/M/H/703, the Adaptive Cushioning System (ACS) handles end-position cushioning.
  • On the RA/802080/M/900/M/H/703: barrel in anodised aluminium, piston rod in martensitic stainless steel with male thread, seals in polyurethane (PU).
  • The RA/802080/M/900/M/H/703 is designed for -20 to 80 °C.

Applications

The cylinder is used for lifting, clamping and diverting in conveying and handling equipment, sized for 80 mm bore and 900 mm stroke.

Technical data

Product lineISOLine
SeriesRA/802000/M
StandardISO 15552, VDMA 24562
Operating modedouble-acting
Bore80 mm
Stroke900 mm
PortG3/8
Theoretical force at 6 bar3016 N
Operating pressure1 to 16 bar
Mediumcompressed air
Temperature range-20 to 80 °C
CushioningAdaptive Cushioning System (ACS)
Magnetic pistonyes
Barrelanodised aluminium
Piston rodstainless steel (martensitic)
Piston rod threadmale thread
Piston sealpolyurethane (PU)
Piston rod sealpolyurethane (PU)
ManufacturerNorgren
Hersteller-NrRA/802080/M/900/M/H/703
Zolltarifnummer84123100
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Piston Ø [mm]80
Stroke [mm]900
Seal materialPU
Housing materialAluminium, anodised
Functiondouble-acting
NormISO 15552, VDMA 24562
Betriebsdruck max [bar]16
Pneumatic connectionG3/8
Temperaturbereich-20-80 °C
Temperature (max.)80
