R17 Series general purpose regulator, 3/4 PTF, 0.3-3.5 bar, without gauge - Norgren R17-600-RNEA

Pressure regulators keep the working pressure constant even when the line pressure varies. The R17 Series general purpose regulator Norgren R17-600-RNEA regulates the outlet pressure in the range 0.3 to 3.5 bar and is manufactured in Mexico.

Benefits

• Accurate and quick response to demand and line pressure changes
• The balanced valve keeps inlet pressure changes away from the outlet
• The relieving version reduces outlet pressure even when the system is dead-ended
• Port size 3/4 PTF
• Outlet pressure adjustable from 0.3 to 3.5 bar
• Flow 208 dm³/s

Applications

The regulator sits ahead of cylinders, tools and valve islands that need a fixed working pressure.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive.
