R17 Series general purpose regulator, 1 PTF, 0.3-8.5 bar, without gauge - Norgren R17-801-RNLA
Regulation stays even when demand changes. The R17 Series general purpose regulator Norgren R17-801-RNLA is suitable for compressed air and covers the temperature range -34 to 80 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Pressure regulators keep the working pressure constant even when the line pressure varies. The R17 Series general purpose regulator Norgren R17-801-RNLA accepts an inlet pressure up to 20 bar and reaches a flow of 227 dm³/s.
Benefits
- Accurate and quick response to demand and line pressure changes
- The balanced valve keeps inlet pressure changes away from the outlet
- The relieving version reduces outlet pressure even when the system is dead-ended
- Port size 1 PTF
- Outlet pressure adjustable from 0.3 to 8.5 bar
- Flow 227 dm³/s
Applications
The regulator sits ahead of cylinders, tools and valve islands that need a fixed working pressure.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren R17-801-RNLA |
| Series | R17 |
| Regulator type | General purpose |
| Relieving function | Relieving |
| Adjustment | T-bar |
| Adjusting knob | Zinc plated steel |
| Port size | 1 PTF |
| Gauge port | 1/4 PTF |
| Maximum inlet pressure | 20 bar |
| Adjustable outlet pressure | 0.3 to 8.5 bar |
| Flow | 227 dm³/s |
| Medium | Compressed air |
| Temperature range | -34 to 80 °C |
| Body material | Aluminium alloy |
| Spring bonnet | Aluminium alloy |
| Seal material | Nitrile rubber (NBR) |
| Country of origin | Mexico |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | Non-WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | R17-801-RNLA |
| Zolltarifnummer | 84811099 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
