R07 Series general purpose pressure regulator, 1/8 PTF, 0.3-7 bar, without gauge - Norgren R07-100-NNKA

Pressure regulators keep the working pressure constant even when the line pressure varies. The R07 Series general purpose pressure regulator Norgren R07-100-NNKA has a body made of zinc alloy and accepts an inlet pressure up to 20 bar.

Benefits

• Ported regulators for general purpose pneumatic applications
• Relieving operation as standard
• Non-rising adjusting knob with snap-action lock
• Port size 1/8 PTF
• Outlet pressure adjustable from 0.3 to 7 bar
• Flow 6.5 dm³/s

Applications

The regulator sits ahead of cylinders, tools and valve islands that need a fixed working pressure.

Standards and conformity

The version is RoHS compliant, an SVHC substance is present under REACH. The product does not fall under the WEEE directive.
