R07 Series general purpose pressure regulator, 1/4 PTF, 0.3-8.5 bar, with gauge - Norgren R07-200-RGLA

Pressure regulators keep the working pressure constant even when the line pressure varies. The R07 Series general purpose pressure regulator Norgren R07-200-RGLA is suitable for compressed air and regulates the outlet pressure in the range 0.3 to 8.5 bar.

Benefits

• Ported regulators for general purpose pneumatic applications
• Relieving operation as standard
• Non-rising adjusting knob with snap-action lock
• Port size 1/4 PTF
• Outlet pressure adjustable from 0.3 to 8.5 bar
• Flow 7 dm³/s

Applications

Typical installations are production lines, test benches and machines with several pressure levels.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive.
