In service the pinch valve shuts off abrasive, fibrous and solid-laden media by squeezing an elastic sleeve together with compressed air. The decisive figure is the nominal size DN 50 in a full bore. Dimensions G 2", DN 50, 185 mm long, made of aluminium.
Pneumatic pinch valve, G 2", aluminium, sleeve food grade natural rubber, L 185 mm
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€778.15
Item
FL-306784
Manufacturer no.
QVMC 20
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.QVMC 20
EAN4050571562762
Customs tariff number84818087
ConditionNew
Artikel
FL-306784
Frequently Bought Together
-
This Item:
€778.15
-
Pneumatic pinch valve, G 3", stainless steel, sleeve abrasion resistant natural rubber, L 230 mm
€2,273.65
-
Pneumatic pinch valve, G 1-1/2", aluminium, sleeve EPDM, L 160 mm
€607.93
Total price
The pinch valve shuts off abrasive, fibrous and solid-laden media by squeezing an elastic sleeve together with compressed air. The data state the nominal size DN 50 in a full bore. This version is listed with female thread G 2", nominal size DN 50 and overall length 185 mm. The stated material is aluminium.
Benefits
- Nominal size DN 50 over the full bore, so there are no dead spaces and no clogging.
- Female thread G 2" on both sides with an overall length of 185 mm.
- Control port G 1/4" for the compressed air, control pressure up to PN 6.
- Body made of aluminium with a sleeve of food grade natural rubber.
- Temperature range -10 to +80 °C depending on the sleeve material.
- Open in the rest position, the medium flows through the body without being deflected.
Technical data
| Body material | aluminium |
|---|---|
| Version | pinch valve with a natural rubber sleeve (food grade) |
| Female thread G | G 2" |
| Nominal size DN [mm] | 50 |
| Overall length L [mm] | 185 |
| Control port A | G 1/4" |
| Temperature range [°C] | -10 to +80 |
| Sleeve material | food grade natural rubber |
| Rest position | open |
| Control pressure | PN 6 |
| Bore | full cross section, free of dead spaces |
Applications
In process engineering the valve with its 185 mm overall length controls fibrous and solid-laden liquids.
| Weight | 2.200000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | QVMC 20 |
| EAN | 4050571562762 |
| Zolltarifnummer | 84818087 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Quetschventil, Manschette aus Naturgummi (Lebensmittelqualität) |
| Material | Aluminium |
| Temperaturbereich | -10-80 °C |
