Push-in T-fitting male thread 1/2 NPT for tubing O.D. 1/2" QSYL-1/2-1/2-U - Festo 153793
The Festo push-in T-fitting QSYL-1/2-1/2-U connects a male thread 1/2 NPT to two outlets for tubing O.D. 1/2". It can be used from -0.95 to 10 bar and at -10 to 60 °C ambient temperature, so vacuum lines are covered too.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo push-in T-fitting QSYL-1/2-1/2-U connects a male thread 1/2 NPT to two outlets for tubing O. D. 1/2". Following the push-pull principle, the tube (1/2") is simply pushed in and released again via the grey release ring.
Benefits
- Pressure and vacuum -0.95 to 10 bar, so also suitable for vacuum
- Temperature range -10 to 60 °C ambient temperature
- Flow free cross-section with nominal size 10.8 mm
- Grip and sealing clamping segment in high-alloy stainless steel, tubing seal in NBR
- Thread threaded stud with sealing coating, no additional sealant needed
- PWIS PWIS conformity VDMA24364-B1/B2-L, relevant for paint shops
Applications
It saves a separate manifold block when two consumers with tubing O. D. 1/2" share one line. Permitted medium: compressed air to ISO 8573-1:2010 [7:-:-], nominal size 10.8 mm. Lubricated compressed air is also permitted. Housing in PBT, RoHS compliant.
Technical data
| Feature | Value |
|---|---|
| Type | QSYL-1/2-1/2-U |
| Festo part number | 153793 |
| Size | Standard |
| Nominal size | 10.8 mm |
| Type of seal on screwed plug | Coating |
| Mounting position | Any |
| Design | L-shape, 2-way, parallel |
| Construction | Push-pull principle |
| Operating pressure complete temperature range | -0.95 to 10 bar |
| Maritime classification | See certificate |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -10 to 60 °C |
| Product weight | 75 g |
| Number of outputs | 2 |
| Number of supply lines | 1 |
| Type of mounting | External hex 7/8 |
| Pneumatic connection, port 1 | Male thread 1/2 NPT |
| Pneumatic connection, port 2 | For tubing outside diameter of 1/2" |
| Colour of release ring | Grey |
| Note on materials | RoHS compliant |
| Material housing | PBT |
| Material release ring | POM |
| Material tubing seal | NBR |
| Material tubing clamp component | High-alloy stainless steel |
| Weight | 0.085 kg |
| Manufacturer | Festo |
| Hersteller-Nr | QSYL-1/2-1/2-U |
| EAN | 4052568310752 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | PBT |
| Bauform | L-Form, 2-fach, parallel |
| Thread | NPT 1/2 AG |
| Nominal size DN [mm] | 10,8 |
| Size BG | Standard |
| Seal material | NBR |
| Medium | Compressed air |
| Series | QSYL |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | NPT 1/2 AG |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
