Bulkhead push-in fitting female thread 3/8 NPT for tubing O.D. 1/2" QSSF-3/8-1/2-U - Festo 153777
The Festo bulkhead push-in fitting QSSF-3/8-1/2-U passes tubing with O.D. 1/2" through a wall or panel and provides a female thread 3/8 NPT on the other side. It can be used from -0.95 to 10 bar and at -10 to 60 °C ambient temperature, so vacuum lines are covered too.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo bulkhead push-in fitting QSSF-3/8-1/2-U passes tubing with O. D. 1/2" through a wall or panel and provides a female thread 3/8 NPT on the other side. To connect, just push in the tube (1/2"), the grey release ring frees it again.
Benefits
- Pressure and vacuum -0.95 to 10 bar, so also suitable for vacuum
- Temperature range usable at -10 to 60 °C
- Flow nominal size 11 mm
- Grip and sealing clamping segment in high-alloy stainless steel, tubing seal in NBR
- PWIS PWIS conformity VDMA24364-B1/B2-L, relevant for paint shops
- Mounting External hexagon 1
Applications
For control cabinets, machine guards and housing walls through which a line with tubing O. D. 1/2" is routed. Permitted medium: compressed air to ISO 8573-1:2010 [7:-:-], nominal size 11 mm. Lubricated compressed air is also permitted. Nickel-plated housing, RoHS compliant.
Technical data
| Feature | Value |
|---|---|
| Type | QSSF-3/8-1/2-U |
| Festo part number | 153777 |
| Size | Standard |
| Nominal size | 11 mm |
| Type of seal on screwed plug | Coating |
| Mounting position | Any |
| Design | Bulkhead |
| Construction | Push-pull principle |
| Operating pressure complete temperature range | -0.95 to 10 bar |
| Maritime classification | See certificate |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -10 to 60 °C |
| Product weight | 66 g |
| Type of mounting | External hexagon 1 |
| Pneumatic connection, port 1 | Female thread 3/8 NPT |
| Pneumatic connection, port 2 | For tubing outside diameter of 1/2" |
| Colour of release ring | Grey |
| Note on materials | RoHS compliant |
| Material housing | nickel-plated |
| Material release ring | POM |
| Material tubing seal | NBR |
| Material tubing clamp component | High-alloy stainless steel |
| Weight | 0.085 kg |
| Manufacturer | Festo |
| Hersteller-Nr | QSSF-3/8-1/2-U |
| EAN | 4052568310592 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Bauform | Schott |
| Thread | NPT 3/8 |
| Nominal size DN [mm] | 11 |
| Size BG | Standard |
| Seal material | NBR |
| Medium | Compressed air |
| Series | QSSF |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | NPT 3/8 IG |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
